PLUG IN AND RECORD DIRECT TO YOUR PHONE!

Made exclusively for ISOLO users, the AR1 Key Chain Recorder enables extensive functionality such as digital recording and real-time monitoring. Just connect AR1 to your phone to record or share your content anytime, anywhere. You can also link with various music apps via USB audio to discover endless possibilities in teaching, learning, and creating.

AR1 Recorder Specs

① 1/4” (6.3mm) signal plug	Connect to “Output” of all ISOLO receivers
② Power switch	◎Push to Rec side to activate AR1, push to the opposite side to turn off ◎To recharge AR1, use USB power cable while AR1 is OFF
③ 1/8” (3.5mm) audio output	Use 1/8” (3.5mm) TRS cable to send signal to speakers or mixers
④ Micro USB port	◎When AR1 is on, this is where you connect your device for recording ◎When AR1 is off, this is the port for recharging
⑤ Headphone volume control	Rotate to adjust headphone volume. This WILL NOT change the volume of your recording.
⑥ Headphone output	Use 1/8” (3.5mm) TRS cable to connect with your headphones
⑦ Battery status indicator	The color will change according to the battery status. ◎Blue: battery > 80% ◎Green: battery between 80%~30% ◎Red: battery less than 30%
⑧ Signal indicator	This indicator provides visual aid to adjust your balance. 🟢 or below: Signal is too weak, need to increase ISOLO master volume 🟢🟢 ~ 🟢🟢🟢: Signal is OK! Can adjust a little to your preference. 🔴: Signal is quite strong, need to take care. 🔴🔴🔴: Signal is too strong, need to lower ISOLO master volume to avoid clipping.

AR1 Recorder Information

Dimensions	105mm(L)*40mm(W)*21mm(H) ±2mm
Weight	46g ± 2g
Power supply	Built-in rechargeable battery
Battery life	Runs up for 5 hours after a 2 hour complete recharge. Recharge through USB port.
Audio format	24bit, 48KHz
Signal Input	1/4” (6.3mm) TS jack
Headphone output	1/8” (3.5mm) TRS, maximum output 125mW
Audio output	1/8” (3.5mm) TRS
Compatibility	◎iOS: iOS 12 and above ◎PC & Mac ◎Android: Above Android 9.0 and able to activate OTG *Since Android is open source system, compatibility may vary among various models. Cloudvocal DOES NOT guarantee full support to Android devices nor Apps.
